Stand Up Pouch Packaging Machine Self-supporting Bag Packing Equipment
| MOQ: | 1 |
| Prijs: | Negotiations |
| Standaardverpakking: | Internationale standaardverpakking voor verzending |
| Leveringstermijn: | 30 dagen |
| Betalingswijze: | L/C, T/T, Western Union |
| Toeleveringskapaciteit: | 300 sets per jaar |
Gedetailleerde informatie
Plaats van herkomst
Sjanghai
Merknaam
Waylead
Certificering
/
Modelnummer
WG-250
Document
Verpakkingssnelheid:
≦70 zakken/min
Zakformaat:
Lengte: ≦400 mm, breedte: 130-260 mm
Filmmateriaal:
Platte zakken, stazakken, zakken met ritssluiting, zakjes van composietfilm en andere soorten.
Voeding:
380V
Luchtverbruik:
5-7kg/cm2; 0,4m3/min
Vermogenstype:
Elektrisch
Stroomverbruik:
8 kW
Materiaal:
Stianloos staal
Verpakkingsassortiment:
Korrels Poeder Vloeistof
Productbeschrijving
This stand up pouch packaging machine is specially optimized for self-supporting pouch packaging demands, with stable operation for different bag thicknesses and materials including plastic, composite and aluminum foil. It adopts servo-driven film pulling mechanism, which ensures the bag shape is neat and the sealing edge is firm without wrinkling, effectively improving the finished product qualification rate. The machine is equipped with touch screen operation panel, allowing users to preset parameters such as bag length, filling volume and sealing temperature, which is easy for operators to master. It can be connected with different material feeding systems to adapt to various packaging scenarios. The whole machine runs with low noise and low failure rate, and it can maintain long-term stable operation even in high-temperature and high-humidity factory environments. We provide 7/24 remote technical support to help users solve operation problems in time.
Technical Specifications
| Model | WG-210 | WG-250 | WG-300 |
|---|---|---|---|
| Bag Size | Length: 120-380mm Width: 90-210mm |
Length: ≤400mm Width: 130-260mm |
Length: ≤400mm Width: 160-300mm |
| Packing Speed | ≤70 bags/min | ≤70 bags/min | ≤65 bags/min |
| Work Stations | 8 | 8 | 8 |
| Packaging Formats | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches |
| Power Supply | 380V | 380V | 380V |
| Total Power | 8Kw | 8Kw | 8Kw |
| Air Consumption | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min |
| Film Material | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films |
| Machine Weight | 500kg | 580kg | 850kg |
| Machine Dimensions | 1700*1140*1470 mm | 1850*1250*1520 mm | 2100*1500*1520 mm |
Application Range
Block Items
Candy, chocolate, rock candy, biscuits, pastries, peanuts, green beans, pistachios, nuts, cooked food, pickles, puffed foods, daily necessitiesParticles
MSG, chicken essence, sugar, melon seeds, nuts, capsules, granular medicines, seeds, feed, pesticides, fertilizers, chemical raw materialsPowders
Condiments, monosodium glutamate, salt, glucose, refined sugar, milk powder, washing powder, pesticides, fertilizers, chemical raw materialsLiquids
Rice wine, soy sauce, rice vinegar, juice, beverages, detergentsSauces
Tomato sauce, peanut butter, jam, chili sauce, bean pasteOther Materials
Various other products suitable for bagging Advantage Features
- Designed in accordance with GMP standards and CE certified
- Full servo control system for reliable, fast, and precise operation
- Empty bag tracking and monitoring device prevents sealing without bag opening, saving packaging materials
- Eight-station structure with centralized control via programmable PLC and six flat touch screens for simple operation
Complete Packaging Machine Range
Shanghai Waylead Intelligent Technology Co.,Ltd. is specialized in turn-key solutions for packaging processing projects and fruit/vegetable processing lines. The company focuses on packaging equipment, robot applications, fruit and vegetable processing equipment, etc., and is committed to the fruit and vegetable processing industry, baking industry, snack food industry, freeze-drying industry, and powder industry. sauce industry, hardware chemical industry and other one-stop professional services.
Our comprehensive packaging solutions include VFFS machines, flow wrapping machines, heat shrink packaging, pouch packing machines, and complete automated packaging lines with weight inspection, metal detection, carton packing, sealing, coding, and palletizing systems.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a manufacturer, providing quality products at factory price. Welcome to visit us!
What quality guarantee or warranty do you provide?
We provide high-quality machines with a 3-year warranty and lifetime technical support.
When can I get the machine after payment?
Delivery time depends on the specific machine model ordered.
How do you provide technical support?
24/7 support via phone, email, or messaging platforms; installation guides and videos; overseas engineering services available.
How does your after-sales service work?
Machines are pre-adjusted before shipment with free training available. Lifetime technical support provided via multiple communication channels.
How about spare parts?
We provide a comprehensive spare parts list for reference.
Can you help with custom design requirements?
Customized design available with our experienced mechanical engineers.
Can you help analyze and design machines for new product samples?
Yes, our technical department can analyze, design, and test new products you provide.
How do I start an order?
30% deposit after signing contract, production arrangement, pre-shipment testing and inspection, balance payment before shipment.
Can you send product catalog and price list?
Electronic catalog available. Please consult us for specific product pricing.
Can I visit your factory?
Yes, welcome to visit our factory at Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China.
